Regulator with Automatic Reverse

Flow Rate 12 kg/h

COMPLIANT WITH EN 16129 RULE

sku model price info add to cart

00000002600

REGULATOR WITH AUTOMATIC REVERSE - IN MAL W20LH-UNI OUT MAL W20LH-UNI - flow rate 12 kg/h

147,00 Excl. Taxes

Physical data

UM Base:
NR

Dimension:
23 × 13 × 14 cm

Volume:
0.0042 m3

Weight:
0,80 kg

Minimum Order Quantity:
1

Customs data

Customs Code
84811099

Buy
Info Request

Product informations

High pressure regulator with automatic reverser, designed to allow for priority gas withdrawal from the service cylinder and not to collect gas from the reserve one unless the one in service is no longer able to ensure the required gas supply; thus ensuring a continuous flow of gas without interrupting the service to the appliance and maximizing the quantity of gas available in the cylinders.

Equipped with two inlet connections with non-return valves that prevent gas from leak when changing the cylinder and filters that prevent entry of dirt.

Technical Features

TYPES OF GAS LPG
FLOW RATE 12 kg/h
OPERATING TEMPERATURE - 20°C ÷ + 50°C
INLET PRESSURE 2 ÷ 16 bar
OUTLET PRESSURE 1,5 bar
CONNECTION IN MAL W20LH-UNI - OUT MAL W20LH-UNI
