Flow Meter for Pipes

For pipes from 1" to 8"

COMPLIES WITH CE STANDARD: EN 60730-2-15:2010-03

	sku	model	price	info	add to cart
	00000070165	FLOW METER FOR PIPES - Ø 1"	€136,00 Excl. Taxes	Physical data UM Base: NR Dimension: 19 × 8 × 16 cm Volume: 0.0025 m³ Weight: 0,67 kg Minimum Order Quantity: 1 Customs data Customs Code 90322000	Flow Meter for Pipes quantity Buy Info Request

Flow meter designed to control the flow in pipes from 1" to 8", moreover, in the absence of water, it has the function of a protection switch.

CONTACTS	dust-tight microswitch with switching contacts (n.c./n.o.)
MAX TEMPERATURE	120°C
MAX PRESSURE	11 bar
DEGREE OF PROTECTION	IP65 (protected against jets of water pumped from any direction and completely hermetic against dust and fumes)
PROTECTION CLASS	I
POWER SUPPLY	230 Vac
CONNECTION	1"
MATERIALS	ABS base transparent PVC cover AISI 316L stainless steel small shovels
DIMENSIONS	140 x 62 x 65 mm (WxDxH)
SMALL SHOVELS DIMENSIONS	28,5 mm 54,5 mm 83,5 mm 161,5 mm
